Cavity Cartridge Fuse Micro Fuse Description
F09 40 Amp Green
(Special Ser-
vices Vehicle
& Cummins
Diesel)
– Diesel Fuel Heater – If Equipped
F10 40 Amp Green – Body Controller / Exterior Lighting #2
F10 50 Amp Red – Body Controller / Exterior Lighting #2 –
If Equipped with Stop/Start
F11 30 Amp Pink – Integrated Trailer Brake Module – If
Equipped
F12 40 Amp Green – Body Controller #3 / Power Locks
F13 40 Amp Green – Blower Motor
F14 40 Amp Green – Body Controller #4 / Interior Lighting
F16 30 Amp Pink – Smart Bar – If Equipped
F19 20 Amp Blue
(1500 LD
Diesel)
30 Amp Pink
(Cummins
Diesel)
– SCR – If Equipped
F20 30 Amp Pink – Passenger Door Module
F21 30 Amp Pink – Drive Train Control Module
F22 20 Amp Blue
30 Amp Pink
(Cummins
Diesel)
– Engine Control Module
F23 30 Amp Pink – Body Controller #1 / Interior Lighting
F24 30 Amp Pink – Driver Door Module
F25 30 Amp Pink – Front Wiper
F26 30 Amp Pink – Antilock Brakes / Stability Control Module
/ Valves
F28 20 Amp Blue – Trailer Tow Backup Lights – If Equipped
F29 20 Amp Blue – Trailer Tow Parking Lights – If Equipped
F30 30 Amp Pink – Trailer Tow Receptacle
F31 30 Amp Pink
(1500 LD
Diesel)
– Urea Heater Control – If Equipped
F32 – – Spare Fuse
F33 20 Amp Blue – Special Services Vehicle Only
F34 30 Amp Pink – Vehicle System Interface Module #2 –
If Equipped
F35 30 Amp Pink – Sunroof – If Equipped
F36 30 Amp Pink – Rear Defroster – If Equipped
