364 SERVICING AND MAINTENANCE
Circuit Breakers
F58 20 Amp Blue – Direct Battery Feed *
F60 50 Amp Red – Mod Inverter *
F61 – – Spare
F62 A&B – 10 Amp Red
ITBM / Mod Occupant Class / Mod IAIR Suspension / Mod HVAC / Snsr
In car Temp / Integrated Radar Camera Mod (IRCM) / Humidity Rain &
Light Sensor (HRLS) / Parktronics System Mod (PTS) / Gateway Can-C
Trailer TPM Mod
F63 – – Spare
F64 – – Spare
F65 – 10 Amp Red Mod ORC
F66 – 10 Amp Red Run - Accessory Feed
Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
Cavity Circuit Breaker Description
CB1 25 Amp
Driver Window SW Rear PWR Windows / Overhead SW Rear
Defrost
CB2 25 Amp Driver PWR Seat / Driver Seat Memory Mod
CB3 25 Amp Passenger Power Seat / Passenger Seat Memory Mod
