AUXILIARY SWITCHES
There can be up to five auxiliary switches located in the lower switch
bank of the instrument panel, which can all be used to power various
electronic devices and PTO (Power Take Off) – if equipped. Connec-
tions to the switches are found under the hood in the connectors
attached to the auxiliary Power Distribution Center.
The system has the ability to configure the functionality of the auxiliary
switches via the Instrument Cluster Display. All switches can now be
configured for ignition or battery power, saving or not saving the state
across a key cycle, and momentary or latching switch operation.
For further information on using the auxiliary switches, please refer to
the Ram Body Builders Guide by accessing www.rambodybuilder.com
and choosing the appropriate links.
For general questions on upfitting commercial vehicles, including:
• Loose rear park assist installation
• Programmable auxiliary switches
• PTO (Power Take Off) system
• Wiring diagrams
• Vehicle dimensions
• Snow plow installation
• Weight charts and trailer towing
Please consult the Body Builders Guide at www.rambodybuilder.com.
For further information, and applicable warnings and cautions, please refer
to your Owner's Manual at
www.ramtrucks.com/en/owners/manuals.
