Cavity Maxi Fuse Mini Fuse Description
F07
50 Amp Red
(non A/C)
60 Amp Blue
(A/C)
–
Engine Cooling Fan - 1st
Speed
F08 40 Amp Orange –
Passenger Compartment
Blower
F09 – 15 Amp Blue Rear Power Outlet
F10 – 15 Amp Blue Horn
F11 – 15 Amp Blue
Fuel Pressure Regulator
(MPROP)-DRV (3.0 Diesel
Engine) — If Equipped
F14 – 20 Amp Yellow Power Outlet
F15 – 7.5 Amp Brown USB Charger
F16 – 7.5 Amp Brown
KL15 Shifter Transmission
Module (STM) (3.6), KL15
Starter Relay Coil (3.6 Gaso-
line Engine)
F16 – 7.5 Amp Brown
KL15 Manual Transmission
Automated (MTA), KL15 Shift
Lever Unit, KL15 Engine Con-
trol Module (ECM), KL15
Starter Relay Coil (3.0 Diesel
Engine)
F17 – 20 Amp Yellow
Engine Control Module (ECM),
Injectors (3.6 Gasoline Engine)
F17 – 20 Amp Yellow
Secondary Loads, Engine Con-
trol Module (ECM) (3.0 Diesel
Engine)
F18 – 7.5 Amp Brown
KL30 Engine Control Module
(ECM), KL30 Main Relay Coil
(3.6 Gasoline Engine)
F18 – 7.5 Amp Brown
KL30 Manual Transmission
Automated (MTA), KL30
Engine Control Module (ECM),
KL30 Main Relay Coil (3.0
Diesel Engine)
F19 – 7.5 Amp Brown A/C Compressor (If Equipped)
F20 – 30 Amp Green Windshield Wiper
F21 – 15 Amp Blue Fuel Pump
F22 – 20 Amp Yellow
Engine Control Module (ECM),
Ignition Coils (3.6 Gasoline
Engine)
F22 – 20 Amp Yellow
Engine Control Module (ECM),
Primary Loads (3.0 Diesel En-
gine)
