Cavity Maxi Fuse Mini Fuse Description
F02
50 Amp Red (3.0 Diesel En-
gine)
– Glow Plug Unit (3.0 Diesel Engine)
F04
50 Amp Red (3.6 Gasoline
Engine)
–
Secondary Power Distribution Center (PDC) (Trans
Power Relay, Vacuum Pump, KL30 for the Shifter
Transmission Module [STM]) (3.6 Gasoline Engine)
F04
40 Amp Orange (3.0 Diesel
Engine)
– Fuel Filter Heater (3.0 Diesel Engine)
F05 30 Amp Green –
SELESPEED Pump RELE (3.0 Diesel Engine) — If
Equipped
F06
40 Amp Orange (non A/C)
60 Amp Blue (A/C)
– Engine Cooling Fan - 2nd Speed
F07
50 Amp Red (non A/C)
60 Amp Blue (A/C)
– Engine Cooling Fan - 1st Speed
F08 40 Amp Orange – Passenger Compartment Blower
F09 – 15 Amp Blue Rear Power Outlet
F10 – 15 Amp Blue Horn
F11 – 15 Amp Blue
Fuel Pressure Regulator (MPROP)-DRV (3.0 Diesel
Engine) — If Equipped
F14 – 20 Amp Yellow Power Outlet
F15 – 7.5 Amp Brown USB Charger
F16 – 7.5 Amp Brown
KL15 Shifter Transmission Module (STM) (3.6),
KL15 Starter Relay Coil (3.6 Gasoline Engine)
