Installation Steps
NOTE: Actual application may vary slightly from illustrations.
Page 3 of 11
4-Door Model ONLY
Insert middle plastic piece into front door surround
section and secure with a self-drilling screw.
Join front surround section to rear surround
section with a self-drilling screw.
Slide the rear bracket onto the rear surround section.
Insert corner piece of vertical upright into
assembled front and rear surround.
Secure all parts with 5 self-drilling screws.
Repeat this section (steps 1-11) to assemble
passenger’s side door surround.
Position completed door surround onto the vehicle and fit the bracket over the roll bar.
7 8
9 10
11 12
13
