Installation Steps
NOTE: Actual application may vary slightly from illustrations.
Page 6 of 11
TIP: Lift up the main fabric for easier access to the brackets. Line up the brackets then secure with the counter-sink Allen
head screw and nylon lock-nut. See photos below for proper fit:
Fold the top toward the windshield to close. Secure using latches.
Unfold the cover fabric then pull over sound bar and roll cage,
working toward the rear of the vehicle.
Wrap the 2 straps attached to the main section of fabric around
the rear-middle of the sound bar. Insert plastic hooks into the holes
on the underside of the sound bar. Tighten the strap until snug.
Attach the latch to the metal flange. Adjust the hook to fit with slight
tension when latch is closed.
28
29
26
27
30
To Next Page
