PCB15 (RTL) YWR0DA7GKZBA Printed Circuit Board Assy
IC1 YWFA5304P IC
IC2 YWNJM2903D1 IC
IC22,23 YWTA76431S IC
IC100 YWM51957BL IC
IC111 YWTA76431S IC
Q1
Y
2SK2675 FET
Q2,3
Y
YWPC123FY2 Photo Coupler
Q4 2SA1225Y Transistor
Q41 2SB943-PQ Transistor
Q42 2SC1815-Y Transistor
Q43 2SA1015-Y Transistor
Q44 2SD1268-PQ Transistor
Q45 2SD1276A-QR Transistor
Q46 2SB943-PQ Transistor
Q47 2SC1815-Y Transistor
Q100 2SC1740 Transistor
Q111 2SB888AA Transistor
D1
Y
YWD3SB60 Diode
D2,3 YWERB3710 Diode
D4 YWERA9102 Diode
D5 YWMTZJ30AT77 Diode
D6 YWERB3710 Diode
D21
Y
YWD20LC20U Diode
D23 YWMTZJ8R2C Diode
D24 YWMTZJ5.1CT77 Diode
D25
Y
YWSF10SC6 Diode
D26,27 YWERA9102 Diode
D28,41 MA165 Diode
D42 MA165 Diode
D43 YWMTZJ5.1CT77 Diode
D44 YWD4SBS6 Diode
D45,46 YWMTZJ15BT77 Diode
D47,48 MA165 Diode
D49-52 YWAM01Z Diode
D53,54 YWMTZJ24CT77 Diode
D55 YWD4SBS6 Diode
D56 YWMTZJ5.1BT77 Diode
D57 MA165 Diode
D58 YWERA15-04V3 Diode
R1
Y
ERC12ZGM105 Solid 1M ohms 1/2W
R2,3 ERF5TK1R5 Wire Wound 1.5 ohms 5W
R4,5 ERDS2TJ334 Carbon 330K ohms 1/4W
R6 ERG3SJ221 Metal 220 ohms 3W
R7 ERX3SJR22 Metal 0.22 ohm 3W
R8 ERDS2TJ180 Carbon 18 ohms 1/4W
R9 ERG2SJ104 Metal 100K ohms 2W
R10 ERDS2TJ471 Carbon 470 ohms 1/4W
R11 ERDS2TJ105 Carbon 1M ohms 1/4W
R12,13 ERDS2TJ103 Carbon 10K ohms 1/4W
R14 ERDS2TJ102 Carbon 1K ohms 1/4W
R15,16 ERDS2TJ471 Carbon 470 ohms 1/4W
R17 ERDS2TJ241 Carbon 240 ohms 1/4W
R18 ERDS2TJ181 Carbon 180 ohms 1/4W
R19 ERDS2TJ273 Carbon 27K ohms 1/4W
R20
Y
ERC12ZGM156 Solid 15M ohms 1/2W
R21 ERDS2TJ100 Carbon 10 ohms 1/4W
R22 ERDS2TJ221 Carbon 220 ohms 1/4W
R23 ERG2SJ470 Metal 47 ohms 2W
R24 ERDS2TJ470 Carbon 47 ohms 1/4W
R25 ERDS2TJ182 Carbon 1.8K ohms 1/4W
R26 ERDS2TJ562 Carbon 5.6K ohms 1/4W
R27 ER0S2CKF6801 Metal 6.8K ohms 1/4W
R28 ERDS2TJ561 Carbon 560 ohms 1/4W
R29 ER0S2CKF6801 Metal 6.8K ohms 1/4W
R30 ERDS2TJ471 Carbon 470 ohms 1/4W
R31 ERDS2TJ331 Carbon 330 ohms 1/4W
R32 ERDS2TJ222 Carbon 2.2K ohms 1/4W
R33 ER0S2CKF1202 Metal 12K ohms 1/4W
R34 ERDS2TJ621 Carbon 620 ohms 1/4W
R35 ER0S2CKF6801 Metal 6.8K ohms 1/4W
R43 ERDS2TJ221 Carbon 220 ohms 1/4W
R44 ERDS2TJ104 Carbon 100K ohms 1/4W
R45 ERDS2TJ103 Carbon 10K ohms 1/4W
R46 ERDS2TJ821 Carbon 820 ohms 1/4W
R47 ERDS2TJ512 Carbon 5.1K ohms 1/4W
R48 ERDS2TJ821 Carbon 820 ohms 1/4W
R49 ERDS2TJ512 Carbon 5.1K ohms 1/4W
R50,51 ERDS2TJ152 Carbon 1.5K ohms 1/4W
R54
Y
ERQ12AJ4R7P Fuse Resistor 4.7 ohms 1/2W
R55 ERDS2TJ104 Carbon 100K ohms 1/4W
R56 ERDS2TJ472 Carbon 4.7K ohms 1/4W
R57 ERDS2TJ103 Carbon 10K ohms 1/4W
R59 ERDS2TJ222 Carbon 2.2K ohms 1/4W
R60 ERDS2TJ470 Carbon 47 ohms 1/4W
R61 ERDS2TJ181 Carbon 180 ohms 1/4W
R62 ERDS2TJ103 Carbon 10K ohms 1/4W
R63 ERDS2TJ392 Carbon 3.9K ohms 1/4W
R64 ERDS2TJ112 Carbon 1.1K ohms 1/4W
R71 ERDS2TJ392 Carbon 3.9K ohms 1/4W
R72 ERDS2TJ112 Carbon 1.1K ohms 1/4W
R73 ERDS2TJ180 Carbon 18 ohms 1/4W
R74 ERDS2TJ103 Carbon 10K ohms 1/4W
R75 ERDS2TJ222 Carbon 2.2K ohms 1/4W
R76 ERG2SJ220P Metal 22 ohms 2W
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
102
POWER-2 BOARD
