R100 ER0S2CKF8201 Metal 8.2K ohms 1/4W
R101 ER0S2CKF3301 Metal 3.3K ohms 1/4W
R102 ERDS2TJ222 Carbon 2.2K ohms 1/4W
R103 ER0S2CKF2201 Metal 2.2K ohms 1/4W
R104 ERDS2TJ242 Carbon 2.4K ohms 1/4W
C2,6
Y
ECQU2A224MV Plastic 0.22 µF 50V
C7,8 ECOS2EB681CB Electrolytic 680 µF 250V
C9,10 ECKD3F331KB Ceramic 330 pF
C11 ECQV1H224JZ Plastic 0.22 µF 50V
C12 ECQP1H391JZ Plastic 390 pF 50V
C13 ECQV1H104JZ Plastic 0.1 µF 50V
C14 ECQB1H103JZ Plastic 0.01 µF 50V
C15 EEUFC1V390B Electrolytic 39 µF 35V
C16,17
Y
ECKDRS332ME Ceramic 3300 pF
C22,25 EEUFC1A222 Electrolytic 2200 µF 10V
C26-28 ECQV1H104JZ Plastic 0.1 µF 50V
C41 ECQM1104KZ Plastic 0.1 µF 50V
C42 ECQV1H224JZ Plastic 0.22 µF 50V
C43 LPW1E682P1 Electrolytic 6800 µF 25V
C44 ECQV1H104JZ Plastic 0.1 µF 50V
C45 LPW1E682P1 Electrolytic 6800 µF 25V
C46 ECQV1H104JZ Plastic 0.1 µF 50V
C47-50 ECA1EHG331 Electrolytic 330 µF 25V
C51,52 ECQV1H104JZ Plastic 0.1 µF 50V
C53 ECQM2104KZ Plastic 0.1 µF 200V
C54 EC0S1KA102CA Electrolytic 1000 µF 10V
C55 ECQM1103KZ Plastic 0.01 µF 50V
C56,57 ECA1JHG331 Electrolytic 330 µF 63V
C58 ECQM1103KZ Plastic 0.01 µF
C59 ECQV1H104JZ Plastic 0.1 µF 50V
C60 ECOS1CA333EB Electrolytic 33000 µF 16V
C61 ECQB1H103JZ Plastic 0.01 µF 50V
C62 ECA1CHG101B Electrolytic 100 µF 16V
C63 ECA1CHG331B Electrolytic 330 µF 16V
C64 ECQV1H104JZ Plastic 0.1 µF 50V
C65 ECOS1CA333EB Electrolytic 33000 µF 16V
C70 ECA1CHG101B Electrolytic 100 µF 16V
C100 ECA1EHG331B Electrolytic 330 µF 25V
C101 ECQV1H104JZ Plastic 0.1 µF 50V
L3
Y
YWOR9A273F28 Coil
L4
Y
YFBL02RN2R62 Coil
L21
Y
YWMSSX12X8A Coil
L22 YFBL02RN2R62 Coil
L23
Y
YWTC1240 Coil
L24
Y
YFBL02RN2R62 Coil
L25
Y
YWTC1240 Coil
L26,27 YFBL02RN2R62 Coil
L100 YWZBF503S01 Coil
RL1 YWA7X209 Relay
T1
Y
YWAPTA1027A4 Power Transformer
CN36 YWB14BEH 14-pin Connector
CN52 YW510481300 13-pin Connector
CN53 YW510480700 7-pin Connector
T1
Y
YWAPTA1027A4 Power Transformer
CN36 YWB14BEH 14-pin Connector
CN52 YW510481300 13-pin Connector
CN53 YW510480700 7-pin Connector
CN62 YWB2P3VH 2-pin Connector
CN63 YWB7PVH 7-pin Connector
CN64 YWB4BEH 4-pin Connector
CN65 YW510481400 14-pin Connector
CN99 YWB3BXHA 3-pin Connector
F1-3
Y
YWSSFR6R3AF3 Current Fuse 6.3A
E1
Y
YW851040 Fuse Insulator Cap
E52 YWRDA7L52 Wire Assy for AD/DA Board CN52
E53 YWRDA7L53 Wire Assy for AD/DA Baord CN53
E65 YWRDA7L65 Wire Assy for Fader Drive Board CN65
E10 YWA2QA0134A4 Electrode
M57 YWA7DA1075A4 Heat Sink
M58 YWA7DA1072A3 Heat Sink
M59 YWA2PA1131A4 Insulator
M60 YWPUG3630M Heat Sink (x2)
M61
Y
YWAC254 Insulator (x2)
M62
Y
YWAC-256 Insulator
M63 YWPC303030PB Heat Sink
E103
Y
YWKP610S75R AC Power Cord for WR-DA7/B
YWKP4819CE25 AC Power Cord for WR-DA7/G
M101
Y
YWA8QA4842AN Operating Instructions
M102 XZB26X40C05 Polyethylene Bag for WR-DA7/B
YWPE26X40C05 Polyethylene Bag for WR-DA7/G
M103 YWT80X90X1 Polyethylene Bag for WR-DA7/B
YWPE80X90X1A Polyethylene Bag for WR-DA7/G
M105 YWA9CA3704BN Packaging Assy for WR-DA7/B
YWA9CA3716CN Packaging Assy for WR-DA7/G
M106 YWV7SA2037A3 Label
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
103
ACCESSORY PARTS / PACKAGING PARTS
