Ramsa WR-DA7 - Page 76

E101 Y YW26CKIT08W Power Cord
FB1 YWRDU07L01 Flexible Cable
M1 YWA5WA2366B1 Meter Decoration Panel
M2 YWA1VA0519A3 LED Cover
M3 YWA5WA2364A1 Meter Panel
M4 YWA6JA1120A3 Button
M5 YWA2KA1198A1 Meter Sub Chassis
M6 YWA5WA2365A1 Meter Rear Panel
M7 YWSR6N4 Cord Bushing
M8 YWA7QA4849A4 Main Label
PCB1 (RTL) YWRDU07GKZ1A Printed Circuit Board Assy
IC1 YWMC74HC367F IC
IC2 YWTC7S04F IC
IC3 YWM51957BFP IC
IC4,5 YWT7C110F003 IC
IC6 YWTD62M8600FL IC
IC7,8 YWTB62705BFL IC
IC10 YWD78052G145 IC
IC11 YWTC7S08F IC
IC12 YWTC7S04F IC
IC13 MC74HC573AF IC
IC14 YWTC7S04F IC
Q1-5 FMG9AT148 Transistor
Q6,7 2SB766A-QR Transistor
Q8 2SD874A-RS Transistor
Q9 DTC114YKAT46 Transistor
Q10 DTA114YKAT46 Transistor
Q11,12 FMG9AT148 Transistor
D1,2 YWSML210VT86 LED
D3-8 YWSML210DT86 LED
D9-15 YWSML210MT86 LED
D16 YWSML210VT86 LED
D17 YWSML210VT86 LED
D18-23 YWSML210DT86 LED
D24-30 YWSML210MT86 LED
REF. NO. PART NO. DESCRIPTION
104
MISCELLANEOUS
METER BRIDGE BOARD-1
WR-MTBR
D31,32 YWSML210VT86 LED
D33-38 YWSML210DT86 LED
D39-45 YWSML210MT86 LED
D46,47 YWSML210VT86 LED
D48-53 YWSML210DT86 LED
D54-60 YWSML210MT86 LED
D61,62 YWSML210VT86 LED
D63-68 YWSML210DT86 LED
D69-75 YWSML210MT86 LED
D76,77 YWSML210VT86 LED
D78-83 YWSML210DT86 LED
D84-90 YWSML210MT86 LED
D91,92 YWSML210VT86 LED
D93-98 YWSML210DT86 LED
D99-105 YWSML210MT86 LED
D106,107 YWSML210VT86 LED
D108-113 YWSML210DT86 LED
D114-120 YWSML210MT86 LED
D121,122 WSML210VT86 LED
D123-128 YWSML210DT86 LED
D129-135 YWSML210MT86 LED
D136,137 YWSML210VT86 LED
D138-142 YWSML210DT86 LED
D144-150 YWSML210MT86 LED
D151 YWSML210VT86 LED
D152 YWSML210DT86 LED
D153 YWSML210VT86 LED
D154 YWSML210MT86 LED
D155-158 YW1SS355 Diode
D159-164 YWUDZ5.6B Diode
D165 YWUDZ6.2B Diode
R1 YWR1220P912D Metal 9.2K ohms
R2 YWR1220P332D Metal 3.3K ohms
R3 ERJ6GEYJ102 Carbon 1K ohms 1/10W
R4-7 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R8-17 ERJ6GEYJ561 Carbon 560 ohms 1/10W
R18,19 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R20 ERJ6GEYJ471 Carbon 470 ohms 1/10W
R21 ERJ6GEYJ561 Carbon 560 ohms 1/10W
R22 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R23 ERJ14YJ390H Carbon 39 ohms 1/10W
R24 ERJ14YJ470 Carbon 47 ohms 1/10W
R25 ERJ14YJ560H Carbon 56 ohms 1/10W
R26 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R27 ERJ6GEYJ680 Carbon 68 ohms 1/10W
R29,30 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R31-45 ERJ14YJ101 Carbon 100 ohms 1/10W
R46 ERDS2TJ102 Carbon 1K ohms 1/4W
Z1-21 EXBV8V223J Block Resistor
C1 YF400104FZT Ceramic 0.1 µF
REF. NO. PART NO. DESCRIPTION
