Ramsa WR-DA7 - Page 77

C2 EEVHB1C470P Electrolytic 47 µF 16V
C3 YF400104FZT Ceramic 0.1 µF
C5 EEVHB1C220R Electrolytic 22 µF 16V
C7 YF400104FZT Ceramic 0.1 µF
C8,9 YF400103FZT Ceramic 0.01 µF
C10-25 YF400104FZT Ceramic 0.1 µF
C26,27 YW400102XK Ceramic 1000 pF
C28,29 EXFP4102EFW Ceramic 1000 pF
SW1-4 EVQPJS04K Push Switch
X1 YWCCR5R0MC3 Oscillator
CF1-6 ELKE221FA LC Filter
CF7 ELKE103FA LC Filter
L11-14 YWBLM21A601T LC Filter
CN44 YWB13BPHSM3T 15-pin Connector
CN77 YW528082690 26-pin Connector
PCB2 (RTL) YWR0DU07KZ2A Printed Circuit Board Assy
IC1,2 YWTD62M8600FL IC
IC3,4 YWTB62705BFL IC
Q1-8 FMG9AT148 Transistor
D1,2 YWSML210VT86 LED
D3-8 YWSML210DT86 LED
D9-15 YWSML210MT86 LED
D16,17 YWSML210VT86 LED
D18-23 YWSML210DT86 LED
D24-30 YWSML210MT86 LED
D31,32 YWSML210VT86 LED
D33-38 YWSML210DT86 LED
D39-45 YWSML210MT86 LED
D46,47 YWSML210VT86 LED
D48-53 YWSML210DT86 LED
D54-60 YWSML210MT86 LED
D61,62 YWSML210VT86 LED
D63-68 YWSML210DT86 LED
D69-75 YWSML210MT86 LED
D76,77 YWSML210VT86 LED
D78-83 YWSML210DT86 LED
D84-90 YWSML210MT86 LED
D91,92 YWSML210VT86 LED
D93-98 YWSML210DT86 LED
D99-105 YWSML210MT86 LED
D106,107 YWSML210VT86 LED
D108-113 YWSML210DT86 LED
D114-120 YWSML210MT86 LED
D121,122 YWSML210VT86 LED
D123-128 YWSML210DT86 LED
REF. NO. PART NO. DESCRIPTION
105
METER BRIDGE BOARD-2
D129-135 YWSML210MT86 LED
D136,137 YWSML210VT86 LED
D138-143 YWSML210DT86 LED
D144-150 YWSML210MT86 LED
D151,152 YWSML210VT86 LED
D153-158 YWSML210DT86 LED
D159-165 YWSML210MT86 LED
D166,167 YWSML210VT86 LED
D168-173 YWSML210DT86 LED
D174-180 YWSML210MT86 LED
D181,182 YWSML210VT86 LED
D183-188 YWSML210DT86 LED
D189-195 YWSML210MT86 LED
D196,197 YWSML210VT86 LED
D198-203 YWSML210DT86 LED
D204-210 YWSML210MT86 LED
D211,212 YWSML210VT86 LED
D213-218 YWSML210DT86 LED
D219-225 YWSML210MT86 LED
D226,227 YWSML210VT86 LED
D228-233 YWSML210DT86 LED
D234-240 YWSML210MT86 LED
R1-16 ERJ6GEYJ561 Carbon 560 ohms 1/10W
R17 ERJ6GEYJ471 Carbon 470 ohms 1/10W
R18 ERJ6GEYJ561 Carbon 560 ohms 1/10W
R19-33 ERJ14YJ101 Carbon 100 ohms 1/10W
R100-212 ERJ6GEY0R00 Carbon 0 ohm 1/10W
R213-230 ERJ8GCS0R00 Carbon 0 ohm 1/10W
R231-329 ERJ6GEY0R00 Carbon 0 ohm 1/10W
C1,2 YF400104FZT Ceramic 0.1 µF
CN77 YW522072690 26-pin Connector
E10 YWA2QA0134A4 Electrode (X4)
M11 Y YWA8QA4845AN Operating Instructions
M12 YPE26X40C05A Polyethylene Bag
M13 YWA2SA4492A3 Mounting Angle R
M14 YWA2SA4493A3 Mounting Angle L
M15 YWT12X15C03 Polyethylene Bag
M16 YWA8EB0109A4 Polyethylene Bag
M17 YWA9CA3713AN Packaging Assy
M18 YWV7SA2037A3 Bar Cord Label
REF. NO. PART NO. DESCRIPTION
ACCESSORY PARTS / PACKAGING PARTS
