M1 YWA5WA2371A3 Panel
M2 YWXM2Z0021 Special Screw
M3 YWA7QE4852A4 Main Label
IC1 MC74HC541AF IC
IC2 YWT6G22U1057 IC
IC3 AM26LS32ACNS IC
IC4 YWT6G22U1057 IC
IC5 YWSN75179BPS IC
IC6 YWTC7S04F IC
IC7 YWTC7W74FL IC
IC8 AM26LS31CNS IC
IC9 YWT74VHC541F IC
Q1 YWDTC114EK97 Transistor
D21 YWUDZ5.1B Diode
R1 ERJ6GEYJ103 Metal 10K ohms 1/10W
R8 ERJ6GEYJ681 Metal 680 ohms 1/10W
R9 ERJ14YJ111 Metal 110 ohms 1/14W
R10,11 ERJ6GEYJ681 Metal 680 ohms 1/10W
R12 ERJ14YJ111 Metal 110 ohms 1/14W
R13,14 ERJ6GEYJ681 Metal 680 ohms 1/10W
R15 ERJ14YJ111 Metal 110 ohms 1/14W
R16,17 ERJ6GEYJ681 Metal 680 ohms 1/10W
R18 ERJ14YJ111 Metal 110 ohms 1/14W
R19,20 ERJ6GEYJ681 Metal 680 ohms 1/10W
R21 ERJ14YJ111 Metal 110 ohms 1/14W
R22 ERJ6GEYJ681 Metal 680 ohms 1/10W
R23-32 YF2116100JT Metal 10 ohms 1/10W
R33 ERJ6GEYJ223 Metal 22K ohms 1/10W
R34 ERJ6GEYJ103 Metal 10K ohms 1/10W
C1,2 YF400104FZT Ceramic 0.1 µF
C3 EEVHB1C470P Electrolytic 47 µF 16V
C4-20 YF400104FZT Ceramic 0.1 µF
C21-24 YF400470CHJT Ceramic 47 pF
C25 YF400104FZT Ceramic 0.1 µF
C26-29 YF400470CHJT Ceramic 47 pF
C30 YF400104FZT Ceramic 0.1 µF
C31-34 YF400470CHJT Ceramic 47 pF
C35 YF400104FZT Ceramic 0.1 µF
C36-39 YF400470CHJT Ceramic 47 pF
C40 YF400104FZT Ceramic 0.1 µF
C41-44 YF400470CHJT Ceramic 47 pF
C45 YF400104FZT Ceramic 0.1 µF
C46-49 YF400470CHJT Ceramic 47 pF
REF. NO. PART NO. DESCRIPTION
106
MISCELLANEOUS
MAIN BOARD
WR-TNDM
C50 YF400104FZT Ceramic 0.1 µF
C51-54 YF400470CHJT Ceramic 47 pF
C55 YF400104FZT Ceramic 0.1 µF
C56-59 YF400470CHJT Ceramic 47 pF
C60 YF400104FZT Ceramic 0.1 µF
C61-64 YF400470CHJT Ceramic 47 pF
C65 YF400104FZT Ceramic 0.1 µF
C66-69 YF400470CHJT Ceramic 47 pF
C70-72 YF400103XKT Ceramic 0.01 µF
C73,74 YF400470CHJT Ceramic 47 pF
C75 YF400104FZT Ceramic 0.1 µF
L1 YWZBF503S01 Coil
L2-23 YWBLM21B03PB Coil
SW1 YWSSSS92057A Slide Switch
CN1 YWXC5A64421A 64-pin Connector
CN2 XM3B2522502 25-pin Connector
M11 Y YWA8QA4857AN Operating Instructions
M12 YWA8EA0079A4 Polyethylene Bag
M13 YWA9CS3714AN Packaging Assy
M14 YWV7SA2037A3 Bar Cord Label
M1 YWA5WA2368A3 TDIF Card Panel
M2 YWXM2Z0021 Special Screw
M3 YWA7QB4852A4 Main Label
REF. NO. PART NO. DESCRIPTION
ACCESSORY PARTS / PACKAGING PARTS
MISCELLANEOUS
WR-TDIF
