Ramsa WR-DA7 - Page 79

IC1 MC74HC240AF IC
IC2 MC74HC540AF IC
IC3 MC74HC4046AF IC
IC4 MC74HC14AF IC
IC5 HD74HC123AF IC
IC6 YWACSA0506BN Custom IC
IC7,8 YWT6G22U1057 IC
IC9 MC74HC541AF IC
IC10,11 YWT74VHC541F IC
IC12 YWT74VHC245F IC
D1-17 DA204K-T46 Diode
R2 ERJ6GEYJ470 Carbon 47 ohms 1/10W
R8 ERJ6GEYJ113 Carbon 11K ohms 1/10W
R9 ERJ6GEYJ133 Carbon 13K ohms 1/10W
R10 ERJ6GEYJ102 Carbon 1K ohms 1/10W
R11 ERJ6GEYJ104 Carbon 100K ohms 1/10W
R14 ERJ6GEYJ103 Carbon 10K ohms 1/10W
R17 ERJ6GEYJ273 Carbon 27K ohms 1/10W
R18 ERJ6GEYJ472 Carbon 4.7K ohms 1/10W
R19,20 ERJ6GEYJ103 Carbon 10K ohms 1/10W
R23,26 ERJ6GEYJ103 Carbon 10K ohms 1/10W
Z1 EXBV8V470J Block Resistor
Z2 EXBV8V471J Block Resistor
Z3,4 EXBV8V472J Block Resistor
Z5-8 EXBV8V222J Block Resistor
C1-32 YF400470CHJT Ceramic 47 pF
C33-36 YF400104FZT Ceramic 0.1 µF
C37 YF400510CHJT Ceramic 51 pF
C38 ECHU1C823JB5 Plastic 0.082 µF 16V
C39 YW400222CHJ Ceramic 2200 pF
C40 YF400103XKT Ceramic 0.01 µF
C41-58 YF400104FZT Ceramic 0.1 µF
C59 ECEV1CA101 Electrolytic 100 µF 16V
C60-62 YF400104FZT Ceramic 0.1 µF
C63 YF400103FZT Ceramic 0.01 µF
C66 ECHU1H153JB5 Plastic 0.015 µF 50V
L1-18 YWBLM21B03PB Coil
SW2 YWSMS502 Dip Switch
CN1 YWXC5A64421A 64-pin Connector
CN2 XM3B2522502 25-pin Connector
M11 Y YWA8QA4857AN Operating Instructions
M12 YWA8EA0079A4 Polyethylen Bag
M13 YWA9CQ3714AN Packaging Assy
M14 YWV7SA2037A3 Bar Code Label
REF. NO. PART NO. DESCRIPTION
107
MAIN BOARD
ACCESSORY PARTS / PACKAGING PARTS
M1 YWA5WA2372A3 Panel
M2 YWA7QF4852A4 Main Label
IC1 MC74HC245AF IC
IC2 MC74HC541AF IC
IC3 YWPD65636055 IC
IC4 YWTC7W04FL IC
IC5 YWMC74HC160F IC
IC6 YWTC7W74FL IC
IC7 YFNJM311M IC
IC8 YWNJM082M IC
IC10 YWHD74HC221F IC
IC11 YWLM1881M IC
IC12 MC74HC4046AF IC
IC13 NJM2903M IC
IC14 MC74HC4046AF IC
IC15 NJM2903MT31 IC
IC16 YWACSA0503AN CustomIC
Q1 DTC144EK Transistor
Q3 2SA1532-CD Transistor
Q4 2SC3930-BC Transistor
Q5 DTC144EK Transistor
Q6 DTC144EK Transistor
D1 YWDA204K Diode
R1 ERJ6GEYJ472 Metal 4.7K ohms 1/10W
R2 ERJ6GEYJ223 Metal 22K ohms 1/10W
R3 YFR1220P222D Metal 2.2K ohms
R4 YWR1220P824D Metal 820K ohms 1/10W
R5,6 YWR1220P103D Metal 10K ohms 1/10W
R7 YWR1220P684D Metal 680K ohms
R8 YWR1220P563D Metal 56K ohms
R9 YWR1220P204D Metal 200K ohms
R11 YWR1220P204D Metal 200K ohms
R12 ERJ6GEYJ101 Metal 100 ohms 1/10W
R13 ERJ6GEYJ103 Metal 10K ohms 1/10W
R14 ERJ6GEYJ184V Metal 180K ohms 1/10W
R15 ERJ6GEYJ224 Metal 220K ohms 1/10W
R16 ERJ6GEYJ684 Metal 680K ohms 1/10W
R17 YWR1220P181D Metal 180 ohms
R18 YWR1220P221D Metal 220 ohms
R19 YWR1220P272D Metal 2.7K ohms
R20 YWR1220P361D Metal 360 ohms
R21 YWR1220P221D Metal 220 ohms
REF. NO. PART NO. DESCRIPTION
MISCELLANEOUS
MAIN BOARD
WR-SMPT
