Ramsa WR-DA7 - Page 80

R22 YWR1220P202D Metal 2K ohms
R23 ERJ6GEYJ750 Metal 75 ohms 1/10W
R24 YWR1220P472D Metal 4.7K ohms
R25 YFR1220P113D Metal 11K ohms
R26 R1220P133D Metal 13K ohms
R27 YWR1220P273D Metal 27K ohms
R28 ERJ6GEYJ273 Metal 27K ohms 1/10W
R30 ERJ6GEYJ562 Metal 5.6K ohms 1/10W
R31 ERJ6GEYJ472 Metal 4.7K ohms 1/10W
R32 ERJ6GEYJ122 Metal 1.2K ohms 1/10W
R35 ERJ6GEYJ103 Metal 10K ohms 1/10W
R36 YWR1220P472D Metal 4.7K ohms
R37 YWR1220P103D Metal 10K ohms
R38 YFR1220P392D Metal 3.9K ohms
R39 YWR1220P273D Metal 27K ohms
R40 ERJ6GEYJ273 Metal 27K ohms 1/10W
R42 ERJ6GEYJ562 Metal 5.6K ohms 1/10W
R43 ERJ6GEYJ472 Metal 4.7K ohms 1/10W
R44 ERJ6GEYJ122 Metal 1.2K ohms 1/10W
R47 ERJ6GEYJ103 Metal 10K ohms 1/10W
R48,49 ERJ6GEYJ472 Metal 4.7K ohms 1/10W
R53 ERJ6GEYJ101 Metal 100 ohms 1/10W
R54 ERJ6GEYJ561 Metal 560 ohms 1/10W
R55 ERJ6GEYJ101 Metal 100 ohms 1/10W
Z1,2 EXBV8V223J Block Resistor
Z3-6 EXBV8V472J Block Resistor
C1-6 YF400104FZT Ceramic 0.1 µF
C7 EEVHA1C221P Electrolytic 220 µF 16V
C9-11 YF400104FZT Ceramic 0.1 µF
C12 YF400103FZT Ceramic 0.01 µF
C13,14 YF400104FZT Ceramic 0.1 µF
C15 EEVHB1H4R7R Electrolytic 4.7 µF 50V
C16 YF400104FZT Ceramic 0.1 µF
C17 YW400010CHC Ceramic 1 pF
C18,19 YF400104FZT Ceramic 0.1 µF
C21 EEVHB1H100P Electrolytic 10 µF 50V
C22,23 YF400470CHJT Ceramic 47 pF
C24,25 YF400221CHJT Ceramic 220 pF
C26-28 YF400104FZT Ceramic 0.1 µF
C30,31 YF400104FZT Ceramic 0.1 µF
C32 ECEV1AA330NP Electrolytic 33 µF 10V
C33,34 YF400470CHJT Ceramic 47 pF
C35-37 YF400104FZT Ceramic 0.1 µF
C39 ECHU1C153JB5 Plastic 0.015 µF
C40 ECHU1C823JB5 Plastic 0.082 µF
C41 YF400510CHJT Ceramic 51 pF
C42,44 YF400104FZT Ceramic 0.1 µF
C45 ECHU1C153JB5 Plastic 0.015 µF 16V
C46 ECHU1C823JB5 Plastic 0.082 µF 16V
C47 YF400510CHJT Ceramic 51 pF
REF. NO. PART NO. DESCRIPTION
108
C48,49 YF400104FZT Ceramic 0.1 µF
C51 YF400104FZT Ceramic 0.1 µF
L1-6 YWBLM21B03PB Coil
L8 YWBLM21B03PB Coil
CN2 YWNC3FAH10 Connector
CN3 YWP2201A BNC Connector
CN51 YW528523090 30-pin Connector
M11 Y YWA8QA4857AN Operating Instructions
M12 YWA8EA0079A4 Polyethylene Bag
M13 YWA9CC3741AN Packaging Assy
M14 YWV7SA2037A3 Bar Cord Label
M1 YWA5WA2369A3 AES/EBU Card Panel
M2 YWXM2Z0021 Special Screw
M3 YWA7QC4852A4 Main Label
IC2 YWT74VHC541F IC
IC3 YWT74VHC245F IC
IC4 YWT74VHC541F IC
IC6 YWT6G22U1057 IC
IC7 YWTC74ACT04AF IC
IC8 YWTC7W74FL IC
IC9,10 MC74HCT244AF IC
IC11 MC74HC125AF IC
IC13 MC74HC273AF IC
IC15,16 YWTC9271FELP LSI
IC19 YWCS8412CS CustomIC
IC21 MC74HC125AF IC
IC22-24 YWCS8412CS CustomIC
IC25 AM26LS31CNS IC
IC26 MC74HC541AF IC
REF. NO. PART NO. DESCRIPTION
ACCESSORY PARTS / PACKAGING PARTS
MISCELLANEOUS
MAIN BOARD
WR-AESS
