Ramsa WR-DA7 - Page 81

IC30 ACSA0501AN CustomIC
R1 ERJ6GEYJ223 Carbon 22K ohms 1/10W
R2-5 ERJ14YJ111 Carbon 110 ohms 1/10W
R6 ERJ6GEYJ560 Carbon 56 ohms 1/10W
R7 ERJ6GEYJ820 Carbon 82 ohms 1/10W
R8 ERJ6GEYJ470 Carbon 47 ohms 1/10W
R9 ERJ6GEYJ330 Carbon 33 ohms 1/10W
R10,11 ERJ6GEYJ560 Carbon 56 ohms 1/10W
R12 ERJ6GEYJ820 Carbon 82 ohms 1/10W
R13 ERJ6GEYJ470 Carbon 47 ohms 1/10W
R14 ERJ6GEYJ330 Carbon 33 ohms 1/10W
R15,16 ERJ6GEYJ560 Carbon 56 ohms 1/10W
R17 ERJ6GEYJ820 Carbon 82 ohms 1/10W
R18 ERJ6GEYJ470 Carbon 47 ohms 1/10W
R19 ERJ6GEYJ330 Carbon 33 ohms 1/10W
R20,21 ERJ6GEYJ560 Carbon 56 ohms 1/10W
R22 ERJ6GEYJ820 Carbon 82 ohms 1/10W
R23 ERJ6GEYJ470 Carbon 47 ohms 1/10W
R24 ERJ6GEYJ330 Carbon 33 ohms 1/10W
R25 ERJ6GEYJ560 Carbon 56 ohms 1/10W
R28-32 ERJ6GEYJ103 Carbon 10K ohms 1/10W
Z5,6 EXBV8V223J Block Resistor
C1,2 YF400104FZT Ceramic 0.1 µF
C3 EEVHB1H1R0R Electrolytic 1 µF 50V
C5-13 YF400104FZT Ceramic 0.1 µF
C16,18 YF400104FZT Ceramic 0.1 µF
C19,22 YF400104FZT Ceramic 0.1 µF
C23 YF400104FZT Ceramic 0.1 µF
C24 YW400473XK Ceramic 0.047 µF
C25 YF400104FZT Ceramic 0.1 µF
C27,28 YF400104FZT Ceramic 0.1 µF
C29-32 YF400470CHJT Ceramic 47 pF
C33-35 YF400104FZT Ceramic 0.1 µF
C36 YW400473XK Ceramic 0.047 µF
C37 YF400104FZT Ceramic 0.1 µF
C39,40 YF400104FZT Ceramic 0.1 µF
C41-44 YF400470CHJT Ceramic 47 pF
C45,46 YF400104FZT Ceramic 0.1 µF
C47 YW400473XK Ceramic 0.047 µF
C48 YF400104FZT Ceramic 0.1 µF
C50,51 YF400104FZT Ceramic 0.1 µF
C52-55 YF400470CHJT Ceramic 47 pF
C56,57 YF400104FZT Ceramic 0.1 µF
C58 YW400473XK Ceramic 0.047 µF
C59 YF400104FZT Ceramic 0.1 µF
C61,62 YF400104FZT Ceramic 0.1 µF
C63-66 YF400470CHJT Ceramic 47 pF
C67-70 YF400104FZT Ceramic 0.1 µF
C71-74 YF400470CHJT Ceramic 47 pF
C75-77 YF400104FZT Ceramic 0.1 µF
REF. NO. PART NO. DESCRIPTION
109
C78-81 YF400470CHJT Ceramic 47 pF
C82,83 YF400104FZT Ceramic 0.1 µF
C84 YF400104FZT Ceramic 0.1 µF
C85-88 YF400470CHJT Ceramic 47 pF
C89-91 YF400104FZT Ceramic 0.1 µF
C92-95 YF400470CHJT Ceramic 47 pF
C96 YF400104FZT Ceramic 0.1 µF
C99-103 YF400104FZT Ceramic 0.1 µF
L1 YWZBF503S01 Coil
L2-21 YWBLM21B03PB Coil
T1-8 YWPT1099 High Freq Transformer
SW1-4 SSSS92A58A Slide Switch
CN1 XC5A64821A 64-pin Connector
CN2 XM3B2522502 25-pin Connector
M11 Y YWA8QA4857AN Operating Instructions
M12 YWA8EA0079A4 Polyethylene Bag
M13 YWA9CR3714AN Packaging Assy
M14 YWV7SA2037A3 Bar Cord Label
M1 YWA5WA2367A3 ADAT Card Panel
M2 YWA7QA4852A4 Main Label
IC2 ACSA0504AN Custom IC
IC3 MC74HC4046AF IC
IC4 MC74HC14AF IC
IC5 HD74HC123AF IC
IC6 ACSA0505AN Custom IC
IC7,8 YWT6G22U1057 IC
IC9 MC74HC541AF IC
IC10,11 YWT74VHC541F IC
IC12 YWT74VHC245F IC
IC14 TC74HCU04AF IC
REF. NO. PART NO. DESCRIPTION
ACCESSORY PARTS / PACKAGING PARTS
MISCELLANEOUS
MAIN BOARD
WR-ADAT
