15
2.3. Mechanical protective devices
The machine is equipped with the following protective
devices:
• complete panelling protection of all the parts subject
to heat and of the steam and hot water supplier;
• cup-warmer plate supplied with a tray to collect spilt
liquids;
• work surface provided with grill and tray to collect
spilt liquids;
• expansion valve in the hydraulic system and valve
on the boiler to avoid overpressure;
• nonreturn valve on the hydraulic system to avoid
flowing back to the main supply.
2.4. Electric safety devices
The safety devices provided are:
• 12V low tension push buttons an the DE control
key panel;
• thermal protection on the pump motor;
• safe resistance thermal;
• Electronic safety devices.
2.5. Aerial noise
Noise level in the working place does not usually
exceed 70dB(A).
2.6. Vibrations
The machine is supplied with rubber vibration
damping feet. In normal working conditions, the
machine does not produce vibrations harmful to the
operator and the environment.
3. TECHNICAL DATA
3.1. Dimensions and weights (Fig.4)
You’ll find all the technical data for the electric
connection on the machine identification label
Fig. 1.
4. USE
The machine has been designed, manufactured and
protected to be used to make espresso and hot
beverages (tea, cappuccino, etc.). Any other use is
to be considered unsuitable and therefore dangerous.
The manufacturer cannot be held
responsible for any damage caused to
people or things due to unsuitable,
erroneous or irrational use of the
machine.
The operator must always follow the instructions
contained in this manual. In the case of a failure or if
the machine is not working properly, switch it off and
do not attempt any direct repair. Refer exclusively to
a service company.
PUORG1PUORG2PUORG3PUORG4
mmA 09605809010331
mm*1A 0750370790121
mmB 5055665095411
mmC 005005005005
mmD 003003003003
mmH 094094094094
.rtilniyticapacrelioB 5116122
gkthgiewenihcaM 356749211
telniretaW "8/3"8/3"8/3"8/3
eganiardmmØ 41414141
gnigakcaP
memuloV
3
72.044.055,076.0
mmHxPxLsnoisnemiD 006x076x066027x076x019027x076x0511027x076x0931
gkthgiewssorG 366709801
)ylbmessaesacedishtiwsnoisnemidllarevodecuder(1A*
