51
2. DESCRIPTION
The machines in the EPOCA series have been desi-
gned to prepare express coffee and hot beverages.
A positive-displacement pump inside the machine
powers the heater in which the water is heated. By
pressing the appropriate buttons, water is supplied
to the spouts in the form of hot water or steam, ac-
cording to needs.
The water to be used for the beverages is supplied
directly by the water supply, pressurized by the pump
and immediately heated by the steam produced by
the boiler or from an incorporated tank containing a
softener for softening the water by trapping calcium
salts.
2.1. Specifications and composition (Fig.3 - 3.a - 3.b)
The machine is composed of a steel carrying struc-
ture on which the mechanical and electrical compo-
nents are tted. These are completely covered with
panels made of painted polyurethane and stainless
steel.
The beverages are dispensed at the front of the
machine, where all the buttons, control devices and
dispensers are to be found.
There is a cup-warming plate on the top of the ma-
chine.
Legend:
A Semiautomatic system; manual dispensing start
and stop.
B Automatic system; electronic control of coffee
doses dispensed.
C N. of coffee dispensing units.
D N. of steam spouts.
E N. of hot water spouts.
1 Steam tap
2 Steam spout
3 Hot water tap
4 Hot water spout
5 Coffee dispensing unit
6 Coffee dispensing button
7 Boiler water level indicator
8 Gauge
9 Power on-off switch and led
10 Switch and boiler resistance engagement light.
11 Water-tank
12 Water shortage pilot light
2.2. Machine equipment
MOD. E1-S1 MOD. S1 TANK
1 dose filter holder
1 1
2 dose filter holder
1 1
Filters
2 2
Disk for cleaning
1 1
1 mt. supply pipe
1 -
1,5 mt. supply pipe
1 -
1,5 mt. drainage pipe
1 -
Pipe connections
1 1
Doser and presser
1 1
Instruction manual
1 1
Brush
1 1
A B C D E
E1 (Fig.3)
- ok 1 1 1
S1 (Fig.3.a)
ok - 1 1 1
S1 TANK (Fig.3.b)
ok - 1 1 1
