Silvia PID Installation Guide
Copyright © 2006, 2007, 2008 MLG Properties, LLC
Silvia PID Kit
Parts List – Watlow 96 kits
Wiring
Size Color Length Terminal Terminal No. Purpose
#14 red 13” #8 ring ins.
(blue)
male QD full
ins. (blue)
2 high voltage leads to SSR
#20 black 48” female QD full
ins. (red)
stripped and
tinned
1 high voltage power to
controller (hot, or line)
#20 gray 48” female QD full
ins. (red)
stripped and
tinned
1 high voltage power to
controller (neutral)
#22 white 48” #6 ring ins.
(red)
stripped and
tinned
1 DC control to SSR from
controller
#22 red 48” #6 ring ins.
(red)
stripped and
tinned
1 DC control to SSR from
controller
#24 x 2 brown 48” #6 ring,
uninsulated
stripped 1 thermocouple probe
#18 or
#20
green 45” female QD #6 ring or
fork
1 grounding wire
Hardware
• 3/8 inch rubber grommet (for installation in bottom cover of enclosure)*
• 1/4 inch rubber grommet (2 each)*
• M4 x 0.7 nut and lock washer*
• #10-24 x 1/2 inch machine screw w/hex nut, flat washer, lock washer*
• 3/8 or 1/2 inch white plastic cable clamp*
• Small wire ties (black) (8 each)*
• Female-male-male spade terminal (3 each)*
• Adhesive reclosable fastener pads (4 each)*
• Packet(s) of white thermal grease*
• Split cable loom x 20”
• Large wire ties (black) (2 each)
Electronics (and accessories)
• Digital PID temperature controller, 1/16 DIN size
• Solid state relay (SSR), DC control, AC power
• Clear plastic cover for SSR
Enclosure
• Brush finish stainless steel enclosure with 1/16 DIN panel cutout
• Gloss finish black acrylic top and bottom panels for enclosure
• Acrylic “L” bracket (glossy black, or clear)
• #6-32 x 3/8 black oxide or SS machine screws (12 each – preinstalled in enclosure)
• #6-32 x 3/8” machine screw w/ lock washer (ground connection – preinstalled)
Misc.
• CD ROM with installation guide in PDF format
* these items packaged in a small poly bag
