OM-FX SERIES 13
Parts List
ITEM PART NUMBER DESCRIPTION
1 HD CST9801 2.5" SWIVEL CASTER (NO LOCK)--HD CST9801
1A HD CST200 2.5” SWIVEL CASTER (NO LOCK)--HD CST200
2 HD CST9802 2.5" SWIVEL CASTER (WITH LOCK)--HD CST9802
2A HD CST201 2.5” SWIVEL CASTER (WITH LOCK)--HD CST201
3 RP PNL1702 PANEL BACK MACHINE COMP
4 RP END1701 SIDE, EXTERIOR, S/S, RIGHT
5 RP END1702 SIDE, EXTERIOR, S/S, LEFT
6 RP BCK1701 BACK, EXTERIOR
7 HD TRK1101_BASE TRACK, DWR SLIDE L/H 2-1/8 X 28 BAYONET MNT
8 HD TRK1102_BASE TRACK, DWR SLIDE R/H 2-1/8 X 26 (650MM) BAYONET MNT
9 RP CPN0601 PAN CONDENSATE DRAIN
10 EL SWT1604 SWITCH, MAGNETIC
11 RP PNL1701 PANEL ACCESS BACK
12 RP CLP1701 CLIP COUNTER WEIGHT BOTTOM
13 RP LVR1702 LOUVER, S/S, FX-1
13A RP LVR0907 LOUVER, FX-1UC
14 RP TOP1501 TOP, 1100MM X 712MM
14A FOR CHEF STAND TOPS CONSULT FACTORY
15 EL WIR461-90 POWER CORD, 9' 16/3-9O
16 HD WCK1401 CF-SE2001 CONDENSATE 7.00IN X3.00IN X 1/16 IN
