OM-FX SERIES 15
Parts List
ITEM PART NUMBER DESCRITPION
1 RP DRP0602 EVAPORATOR DRAINING DRAIN PAN W/DEFROST ELEMENT
2 PB ELB0313 ELBOW, 1/2" ID X 3/8" ID 90 CU CXC
3 EL PAD1101 PAD, FLEXIBLE HEATING FOIL 6.9" X 15.75" 150W 120V
4 RF COI0603 COIL, 1.00" X 7.00" X 15.7" STAGED FIN EVAPORATOR
5 RP BRK0704 BRACKET FOR HI-LIMIT
6 RF TRM0501 THERMODISC 2-WIRE, OPEN:70 CLOSE:50 SEO-70-T17
7 RP GSK0604 GASKET, MAGNETIC, SLIDE SEAL, PF, 765 X 614mm
8 RF DIF0601 DIFFUSER, LID FOR FX-1, FX-1A, FX-1RE, FX-1REA
8A RF DIF0801 DIFFUSER, LID FOR FX-1UC
9 RF FAN0602 FAN. AXIAL, 40 X 20MM 10.8 CFM,12VDC EVAPORATOR
10 HD HSE0601 HOSE, .375" ID X 1/2" OD POLYETHYLENE FLEXIBLE TUBE
11 PB ELB0701 ELBOW, BARB NYLON 3/8 X 3/8
12 EL CLM550 CLAMP, 1/2" CABLE CLAMP 3308 N*
13 RF CNT1602 THERMISTER, QT COIL SENSOR, BLUE 10'
14 RF CNT1603 THERMISTER, QTI AIR SENSOR, BLACK 10'
