Rane SIXTY-ONE - MIDI Control Change Chart

MIDI Control Change Chart
MIDI control changes initiated by the mixer are dedicated to mixer functions and read only. MIDI out messages may be used to trigger
or control external software functions. The mixer can receive MIDI in control changes for USB record sources, phono sensitivity and
HP/LP lter resonance.
See the control panel graphics on the preceding page.
Functions highlighted in RED are MIDI-Out Mixer controls.
Functions highlighted in GREEN are MIDI-In Mixer controls from the software control panel.
Control
#
Hex # Function Values
0 0x00 Crossfader 0-127, 0x00-0x7F
2 0x02 PGM 1 Contour 0-127, 0x00-0x7F
3 0x03 PGM 2 Contour 0-127, 0x00-0x7F
4 0x04 PGM 1 Left-Right Pan 0-127, 0x00-0x7F
5 0x05 PGM 2 Left-Right Pan 0-127, 0x00-0x7F
7 0x07 USB Aux Level 0-127, 0x00-0x7F
21 0x15 Analog 1 Phono Sensitivity
Value Hex Sensitivity
(mV)
dB
0 0x00 2.5 16.04
1 0x01 3 14.46
2 0x02 3.5 12.12
3 0x03 4 11.96
4 0x04 4.5 10.94
5 0x05 5 (Default) 10.02
6 0x06 5.5 9.19
7 0x07 6 8.44
8 0x08 6.5 7.74
9 0x09 7 7.10
10 0x0A 7.5 6.5
11 0x0B 8 5.94
12 0x0C 8.5 5.41
13 0x0D 9 4.92
14 0x0E 9.5 4.45
15 0x0F 10 4.00
22 0x16 PGM 1 Filter Resonance 0-127, 0x00-0x7F Low to High Resonance
23 0x17 PGM 1 Input Record Source (USB
5-6)
1 0x01 Record A1
2 0x02 Record A2
24 0x18 Analog 2 Phono Sensitivity Same as Analog 1 Phono Sensitivity
25 0x19 PGM 2 Filter Resonance 0-127, 0x00-0x7F Low to High Resonance
26 0x1A PGM 2 Input Record Source (USB
7-8)
1 0x01 Record A3
2 0x02 Record A4
27 0x1B Analog 3 Phono Sensitivity Same as Analog 1 Phono Sensitivity
30 0x1E Analog 4 Phono Sensitivity Same as Analog 1 Phono Sensitivity
33 0x21 Main Record Select, (USB 11-12) 1 0x01 Record Main Mix
2 0x02 Record Mic
63 0x3F FlexFX Wet/Dry 0-127 0x00-0x7F
65 0x41 PGM 1 LP/HP Filter 0-127 0x00-0x7F
66 0x42 PGM 2 LP/HP Filter 0-127 0x00-0x7F
69 0x45 Session In Level 0-127 0x00-0x7F
RANE SIXTY-ONE MIXER FOR SERATO SCRATCH LIVE • OPERATOR’S MANUAL 2.4.4
47
