Rane SIXTY-TWO - MIDI Control Change Chart

MIDI Control Change Chart
Functions highlighted in RED are MIDI-Out Mixer controls.
Functions highlighted in BLUE are MIDI-In mixer controls.
Functions highlighted in GREEN are MIDI-Out Scratch Live or 3rd-party DAW controls.
Control
#
Hex # Function Values
0 0x00 Crossfader 0-127, 0x00-0x7F
1 0x01 FX Depth 0-127, 0x00-0x7F
2 0x02 PGM 1 Contour 0-127, 0x00-0x7F
3 0x03 PGM 2 Contour 0-127, 0x00-0x7F
4 0x04 PGM 1 Left-Right Pan 0-127, 0x00-0x7F
5 0x05 PGM 2 Left-Right Pan 0-127, 0x00-0x7F
7 0x07 USB Aux Level 0-127, 0x00-0x7F
8 0x08 USB Aux Filter 0-127, 0x00-0x7F
16 0x10 LH Scroll Encoder 2’s Complement from 64 / Relative (Binary Offset)
17 0x11 LH Manual Loop Select Encoder 2’s Complement from 64 / Relative (Binary Offset)
18 0x12 RH Scroll Encoder 2’s Complement from 64 / Relative (Binary Offset)
19 0x13 RH Manual Loop Select Encoder 2’s Complement from 64 / Relative (Binary Offset)
20 0x14 FX Time Encoder 2’s Complement from 64 / Relative (Binary Offset)
21 0x15 Analog 1 Phono Sensitivity
Value Hex Sensitivity
(mV)
dB
0 0x00 2.5 16.04
1 0x01 3 14.46
2 0x02 3.5 12.12
3 0x03 4 11.96
4 0x04 4.5 10.94
5 0x05 5 (Default) 10.02
6 0x06 5.5 9.19
7 0x07 6 8.44
8 0x08 6.5 7.74
9 0x09 7 7.10
10 0x0A 7.5 6.5
11 0x0B 8 5.94
12 0x0C 8.5 5.41
13 0x0D 9 4.92
14 0x0E 9.5 4.45
15 0x0F 10 4.00
22 0x16 PGM 1 Filter Resonance 0-127, 0x00-0x7F Low to High Resonance
23 0x17 PGM 1 Input Record Source (USB
5-6)
1 0x01 Record A1
2 0x02 Record A2
24 0x18 Analog 2 Phono Sensitivity Same as Analog 1 Phono Sensitivity
25 0x19 PGM 2 Filter Resonance 0-127, 0x00-0x7F Low to High Resonance
26 0x1A PGM 2 Input Record Source (USB
7-8)
1 0x01 Record A3
2 0x02 Record A4
27 0x1B Analog 3 Phono Sensitivity Same as Analog 1 Phono Sensitivity
30 0x1E Analog 4 Phono Sensitivity Same as Analog 1 Phono Sensitivity
33 0x21 Main Record Select, (USB 11-12) 1 0x01 Record Main Mix
2 0x02 Record Mic
38 0x26 USB Aux Filter Resonance 0-127, 0x00-0x7F Low to High Resonance
39 0x27 FX Flanger Type 0-63, 0x00-0x3F Negative
64-127 0x40-0x7F Positive
RANE SIXTY-TWO MIXER FOR SERATO SCRATCH LIVE • OPERATOR’S MANUAL 2.4.4
55
