Range Master 463724313 - Page 21

21
9
10
Tank Retainer
Insert tank retainer into side brace and secure with #10-24x3/8’’ wing screw.
Heat Shield
Attach heat shield with #10-24x1/2’’ machine screws and #10-24 flange nuts.
Heat
Shield
#10-24X1/2”
Machine Screw
Qty. 2
#10-24
Flange Nut
Qty. 2
#10-24x3/8’’ Wing Screw
Qty. 1
Heat Shield
Back of cart
Wing screw
Tank Retainer
