STEP 7
To assemble the Ash Catcher (F), insert 2 Handle Bolts (4) through 2 Metal Washers (8),
Ash Catcher (F), 2 Fiber Washers (10) and thread into the Ash Catcher Handle (S). Slide the
assembled Ash Catcher into the slots on the right side of the Boom Bowl (B). Aach
Warming Rack (E) to the Top Lid (A) and Boom Bowl (B) by inserng the ends at the back
of the Warming Rack into the holes on each side of the Top Lid (A) and the wire handles at
the front boom of the Warming Rack into the holes on each side of the Boom Bowl (B).
Place the Charcoal Grate (D) in the boom of the Boom Bowl (B) and place the Cooking
Grid (C) on the support edge of the Boom Bowl (B). Aach the Condiment Basket (R) to
the Staonary Legs (G) by inserng the wire handles of the basket into the interior holes
on each Staonary Leg.
