33
9. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
COUNTRY OF DESTINATION: GB/IE/FR/NL/BE/DE/AT/SE/LU
Connections
Electric 230/400 V 50 Hz
Dimensions
Overall height minimum 905 mm maximum 930 mm
Overall width 900 mm
Overall depth 602 mm (to fascia inc. splashback); 610 mm (over hotplate)
Minimum space above hotplate 650 mm
Refer to 'Positioning the Cooker'.
Ratings
ArtNo.313-0002 - 110 induction hob rating
1.4 kW
1.4 kW
2.3 kW
2.3 kW 2.3 kW
Ovens
Main oven Tall oven
Forced air
convection
Multi-function
Multi-function
(with Rapid Response)
Forced air
convection
2.5 kW 2.5 kW 3.7 kW 2.5 kW
Energy eciency class on a scale
of A (more ecient) to G (less ecient)
A A A A
Energy consumption based on standard load 0.85 kWh 0.90 kWh 0.90 kWh 0.95 kWh
Usable volume (litres) 67 67 68 66
Size Large Large Large Large
Time to cook standard load 38 minutes 41 minutes 41 minutes 49 minutes
Surface area of the grid 1400 cm² 1400 cm
2
1400 cm
2
790 cm
2
Grill
2.3 kW
Maximum total electrical load at 230 V (approximate total including oven lights, oven fan, etc.):
Fan oven variant: 17.1 kW
Multi-function oven variant: 17.1 kW
Multi-function oven (with rapid response) variant: 18.3 kW
DocNo.100-0001 - Technical data - 90 induction - GENERIC
