9. Technical Data
INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE USER.
DATA BADGE LOCATION: INSIDE FACE ON THE SIDE OF THE DOOR.
COUNTRY OF DESTINATION: GB, IE.
Dimensions
ArtNo.800-0128 - 45 dishwasher dimensions
550
600 min
570 min
598
820 - 870 max
647 - 717 max
820 - 870
All dimensions in mm
Connections
ELECTRIC
220–240 V 50 Hz
Technical specifications
Capacity 12 place settings
Dimensions: Height x Width xDepth 820-870 (mm) x 598 (mm) x 550 (mm)
Net weight 31.5 kg
Operating voltage / frequency 220-240V 50 (Hz)
Total current 10(A)
Total power 1900(W)
Water supply pressure
Maximum: 1 (Mpa)
Minimum: 0.03 (Mpa)
