SPECIFICATIONS
Operating
Temperature: 0°C to 50°C
Storage
Temperature: -20°C to 85°C
Humidity: 0 to 95% non-condensing
Size: 20" H x 16" W x 8" D
(50.8 cm X 40.6 cm X 20.3 cm)
Weight: 52 lbs. (23.6 kg)
Electrical
AC Input: A11515-XX0XX Models
100-120 VAC, 50/60 Hz
2.1 A rms
Fused at 3 Amps
A11515-XX1XX Models
200-240 VAC, 50/60 Hz
1.1 A rms
Fused at 1.5 Amps
Analog Inputs: Remote Speed Setpoint
0-10 VDC or 4-20mA
Switch Selectable
T
emp./Humidity Inputs 4-20mA
250 ft. (76.2m) maximum
cable length
Analog Outputs:
Speed Feedback
0-10 VDC or 4-20mA
Switch Selectable
Discreet Inputs:
Master Enable, Master
Reset, Rotator Enable
Sourced 24 VDC @ 2.3mA
Active Low - connect input
to ground to activate
Discreet
Outputs: Temperature/Humidity,
Master Overspeed, Master
Underspeed, Master Loss
of Feedback, Master Fault,
Rotator Active, Rotator
Fault, Brake Control Active
High - put out 24 VDC when
active, 0.25A maximum per
output
Pneumatic
Inputs
Supply Air: 1/4" ID x 3/8" OD
110 psi (7.6 bar) maximum,
operating
80 psi (5.5 bar) minimum,
operating
40 micron ltration
Pressure Switches
(Enable Inputs): 15 psi (1.03 bar) minimum
to activate
150 psi (10.3 bar) maximum
Outputs
Control Outputs*: 0.106" ID by 5/32" OD
100 ft. (30.5m) maximum
length to volume booster
Brake Control*: 0.170" ID x 1/4" OD
100 ft. (30.5m) maximum
length to brake valve
assembly
Brake Supply*: 1/4" ID x 3/8" OD
100 psi maximum
100 ft. (30.5m) maximum
length from brake valve
assembly to rotator
General
Fiber Optic
Cable: Maximum length is 150 ft.
(45.7m)
Temperature / Humidity Probe
Temperature
Range: 0-100°C (32-212°F)
Accuracy: ± 0.6°C (± 1°F)
Repeatability: ± 0.3°C (± 0.5°F)
Humidity
Range: 3-95% RH
Accuracy (@ 72°F):
± 2.5% from 20% to 80%
± 3.1% <20%, >80%
Drift: ± 0.1% / °F
Repeatability: ± 1% RH
* Longer tubing lengths may be acceptable de-
pending on overall total lengths of pilot signals
and supply signals and the specic application.
However, longer lengths may degrade overall
speed control performance.
Environmental / Physical
