Ransburg Pulsetrack 2 - Control Panel - Front View; Parts List

1 A11515-XXXXX PulseTrack 2 Speed Control and
Monitor System
Atomizer Card:
2 A11448-00 For A11515-XXX1X, 6" Conical Disk
A11448-03 For A11515-XXX2X, Standard Aerobell
For A11515-XXX8X, Standard Aerobell
W/Brake Option
A11448-05 For A11515-XXX3X, Aerobell 33
For A11515-XXX9X, Aerobell 33 W/Brake Option
A11448-08 For A11515-XXX4X, 6" Unidisk
A11448-09 For A11515-XXX5X, 8" Unidisk/9" Conical Disk
A11448-10 For A11515-XXX6X, 10" Unidisk
A11448-12 For A11515-XXX7X, 12"Unidisk/12" Conical Disk
3 A11454-00 Blank Cover Plate Assembly
4 A11357-02 EMC Cable Gland SYS, ATM1 -
A11358-02 Cable Gland Nut ATM6
5 A11448-20 Temperature/Humidity Card
6 A11453-00 Fitting, Bulkhead, Fiber Optic Cable FO1 - FO6
A11484-00 Compression Nut, Fiber Optic Cable FO1 - FO6
7 LSFI0002-00 Fitting, Bulkhead, Pressure Switch, EN1 - EN6
1/8" NPTF x 1/4" ODT
8 78884-00 Switch, Master Control SW2
9 SSP-6054 Fitting, Brake Solenoid, 1/8" NPTM x 1/4" ODT BR1 - BR6
10 78776-01 Fitting, Bulkhead Union, 5/32" ODT CL1 - CL6
11 41-FTP-1007 Fitting, Swivel, Elbow, 1/4" NPTM x 3/8" ODT SUPPLY
12 A11520-00 Temperature/Humidity Probe Assembly
13 77220-00 Cable Assembly, Temperature/Humidity Probe,
50 ft. (15.2m)
14 76948-00 Switch, AC Power SW1
15 LSME0024-00 Alarm Horn, Speed Fault
16 76960-01 Indicator Lens, Speed Fault R
17 76955-00 Switch, Pushbutton, Master Reset SW3
18 A11458-00 Viewing Door Assembly
A11461-00 Glass Only, Viewing Door
A11462-00 Adhesive Tape, Double Sided
— A11547-00 Brake Valve Assembly (see Figure 3)
Fiber Optic Cable Assembly:
SMC-424-6 Fiber Optic Cable Assembly, 25 ft. (7.6m)
SMC-424-2 Fiber Optic Cable Assembly, 50 ft. (15.2m)
SMC-424-7 Fiber Optic Cable Assembly, 75 ft. (22.9m)
SMC-424-1 Fiber Optic Cable Assembly, 100 ft. (30.5m)
— H-2338 Tubing, Pneumatic, 3/8" OD
— 9704-03 Tubing, Pneumatic, 1/4" OD
— TR-SSEM-548 Tubing, Pneumatic, 5/32" OD
Item #
CONTROL PANEL - FRONT VIEW - PARTS LIST (Figure 17)
Part # Description Notation
