Ransburg Pulsetrack 2 - Control Panel - Inside Cabinet View; Parts List

25 4131-11 Fuse, 3A, 250V, Time Delay, 3AG,
for A11515-XX0XX, 120 VAC Input F1, F2
4131-03 Fuse, 1.5A, 250V, Time Delay, 3AG,
for A11515-XX1XX, 240VAC Input F1, F2
26 A11466-01 24VDC Power Supply, for A11515-XX0XX,
120VAC Input
A11466-02 24VDC Power Supply, for A11515-XX1XX,
240VAC Input
27 A11479-00 PC Board Assembly, Breakout
28 10979-04 Fiber Optic Receiver Module, 4 Channel
29 10979-02 Fiber Optic Receiver Module, 2 Channel
30 25766-106 Pressure Switch EN1 - EN6
31 Solenoid Assembly:
41-VSO-1005 Replacement Solenoid Only SOL1 - SOL6
A11485-01 Solenoid Assembly, 1 Solenoid SOL1
A11485-02 Solenoid Assembly, 2 Solenoids SOL1 - SOL2
A11485-03 Solenoid Assembly, 3 Solenoids SOL1 - SOL3
A11485-04 Solenoid Assembly, 4 Solenoids SOL1 - SOL4
A11485-05 Solenoid Assembly, 5 Solenoids SOL1 - SOL5
A11485-06 Solenoid Assembly, 6 Solenoids SOL1 - SOL6
32 Current to Pressure Transducer Assembly:
A11465-00 Replacement Transducer Only TRD1 - TRD6
A11467-01 Transducer Mounting Manifold Only, 2 Position TRD1 - TRD2
A11467-02 Transducer Mounting Manifold Only, 6 Position TRD1 - TRD6
A11463-01 Transducer Assembly, 1 Transducer TRD1
A11463-02 Transducer Assembly, 2 Transducers TRD1 - TRD2
A11463-03 Transducer Assembly, 3 Transducers TRD1 - TRD3
A11463-04 Transducer Assembly, 4 Transducers TRD1 - TRD4
A11463-05 Transducer Assembly, 5 Transducers TRD1 - TRD5
A11463-06 Transducer Assembly, 6 Transducers TRD1 - TRD6
33 77071-03 AC Line Filter
34 A11477-00 PC Board Assemby, Control Card
Item #
CONTROL PANEL - INSIDE CABINET VIEW - PARTS LIST
(Figure 19)
Part # Description Notation
