Rascal LiteWay 214 & 224 Owner’s Manual
SPECIFICATIONS – MODEL 214
Dimension (L x W x H)
41” x 21” x 36”
104.2 cm x 53.4 cm x 91.5 cm
Weight of Scooter 120 lbs./53.43 kg
Battery 12 volt 15ah x2
Charger 2.0 amp Off Board
Front Wheel Dual 7” x 1.75” Foam
Rear Tire 9” x 3” Foam
Top Speed 4.0 mph/ 6.44 km/hr
Climbing angle 8°
Range 10 miles/16.09km
Max. User weight 300 lbs/136 kg
Ground Clearance 2.0”/5.1 cm
Turning Radius 46 in./106.7 cm
Heaviest Component 38 lbs/17.24 kg
SPECIFICATIONS – MODEL 224
Dimension (L x W x H in)
41” x 21” x 36”
104.2 cm x 53.4 cm x 91.5 cm
Weight 124 lbs./56.25 kg
Battery 12 volt 15ah x2
Charger 2.0 amp Off Board
Front Wheel Dual 7” x 1.75” Foam
Rear Tire 9” x 3” Foam
Top Speed 4.0 mph/ 6.44 km/hr
Climbing angle 8°
Range 10 mi./16.09 km
Max. User weight 300 lbs. / 136kg
Ground Clearance 2” / 5.1 cm
Turning Radius 46”/106.7 cm
Heaviest Component 26.8 lbs. / 12.16kg
Electric Mobility reserves the right to modify specifications if necessary.
Note: Range is calculated under test conditions. Weight, terrain and weather conditions can affect
range of travel.
