Technical Specification - Rascal Powerchair P327 Mini
Wheelchair type Class Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled length x width x height mm (in) 1090 (42.9) x 624 (24.5) x 1165(45.9)
Dimensions with seat and footrest folded length x width x height mm (in) 870 (34.3) x 624 (24.5) x 810 (32)
Maximum carrying capacity kg (lbs) 136 (300)
Mass (weight) including 34 Ah batteries kg (lbs) 81.2 (179)
Mass (weight) of seat kg (lbs) 19.0 (41.9)
Mass (weight) of chassis (heaviest part) with batteries
kg (lbs) 62 (136.7)
Standard battery voltage and capacity Volts and Ampere hours 12V / 34Ah x 2
Type of seat Captain Swivel, reclining, headrest
with folding adjustable arms.
Seat width mm (in) 460 (18)
Joystick Bracket (type) Type Adjustable swing-away
Castor wheel dimensions mm (in) 152.4 x 50 (6 x 2)
Drive wheel dimensions mm (in) 260 x 85 (10.2 x 3.3)
Type of tyres/wheels Type Solid - Puncture-proof
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance from maximum speed
m (ft) 2.1 (6.9)
*Range with standard battery option km (miles) Up to 35 (22.00)
The turn-around width m (ft) 1.18 (3.87)
Turning radius m (ft) 0.65 (2.13)
The maximum safe slope degrees of slope 6° -
Do not exceed, the Powerchair may topple
The maximum climbing ability facing upwards degrees of slope 6°
Maximum user weight @ 6° uphill kg (lbs) 136 (300)
Ground clearance mm (in) 50 (2)
Maximum obstacle climbing ability mm (in) 50 (2)
Maximum safe descendable kerb height mm (in) 50 (2)
Force to operate Joystick control Newtons (lbs) 1 (0.224)
Force to operate Freewheel levers Newtons (lbs) 45 (10.1)
Ambient operating temperature range °C (°F) 2 (35.6) to 40 (104)
This power-chair meets the relevant requirements of ISO 7176:14 2008. Due to a policy of continual improvement,
Electric Mobility Euro Ltd reserves the right to change specifications without prior notice.
26
Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
