Rascal P327 / P327XL / P327SL Powerchair Owner’s Manual & Service Record
Technical Specification - Rascal Powerchair P327 SL
Powerchair type Class Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled length x width x height mm (in) 1120 (44.09) x 690 (27) x 1210 (47.6)
Max height when fully elevated mm (in) 1470 (57.9)
Ground to seat height - lowest position mm (in) 620 (24)
Ground to seat height - highest position mm (in) 870 (34)
Maximum carrying capacity - not to be exceeded kg (lb) 182 (400)
Mass (weight) including batteries kg (lb) 123 (271)
Battery voltage and capacity volts and ampere hours 12v x 55Ah x 2
Type of seat Captain seat with scissor lift mechanism
Wheel size front/rear mm (in) 152 (6) solid / 305 (12) pneumatic
Tyre pressure normal - drive wheels p.s.i. (bar) 35 (2)
Tyre pressure maximum - not to be exceeded p.s.i. (bar) 50 (3.5)
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance from maximum speed metres 1.6 (5.2)
Range on full charge and flat ground km (miles) Up to 32 (20)
The turn-around width m (ft) 1.2 (4)
The maximum safe slope degrees of slope 6˚ - Do not exceed the Powerchair may topple
The maximum climbing ability facing upwards degrees of slope 6˚
Ground clearance mm (in) 50 (2.0)
Maximum obstacle climbing ability mm (in) 50 (2.0)
Maximum safe descendable kerb height mm (in) 50 (2.0)
