Rascal R6 300 - Components; Illustration 1 - Major Components

Rascal R6 300 Scooter Owner’s Manual
EMC Part: 19277200 • Rev. 06 • 09/04/2007
4
Components
Rascal R6 300 Series Scooters consists of the following major components, as shown in Illustration 1. You
should familiarize yourself with the location and general functioning before proceeding.
Illustration 1 — Major Components
MODEL R6 300
4-WHEEL
FRONT END
REAR
SECTION
SEAT
COVERS
DASH CONTROLS
DRIVETRAIN
WHEELS
&
TIRES
HANDLEBAR
ASSEMBLY
