Technical Specification - Rascal Vecta Sport Scooter
Wheelchair type Class Class A, B or C Class C
Department of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1320 (52) x 600 (23.6) x 1160 (45.7)
Dimensions seat back and tiller folded length x width x height mm (in) 1320 (52) x 600 (23.6) x 939 (37)
– If bolt not removed then 1117 (44)
Maximum carrying capacity kg (lb) 160 (355)
Lighting Type LED – front and rear
Mass (weight) including 50 Ah batteries kg (lbs) 113 (249.9)
Mass (weight) of chassis (heaviest part) kg (lbs) 95 (210.1)
with 50 Ah batteries
Standard battery voltage and capacity volts and ampere hours 12V / 50Ah x 2
Type of seat Captain (enhanced) - swivel, head rest, reclining/folding back & arms with
width adjustment and seat- slide function.
Mass (weight) of swivel seat kg (lbs) 18 (39.8)
Wheel diameter mm (inch) 305 (12”)
Tyre dimensions front & rear 80 / 65-8
Type of tyres type Run-flat pneumatic – “Runon tyres”™
Tyre Pressures normal p.s.i. (bar) 35 (2.4)
Maximum speed km/h (m.p.h.) 12.87 (8)
Minimum braking distance from maximum speed m (ft) 2.2 (7.2)
Range* km (miles) Up to 44 (27.3)
The turn-around width m (ft) 1.7 (5.5)
Turning diameter m (ft) 3.47 (11.38)
The maximum safe slope degrees of slope 10˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 10˚
Maximum user weight @ 10˚ uphill kg (lbs) 160 (355)
Maximum user weight @ 10˚ downhill kg (lbs) 160 (355)
Ground clearance mm (in) 100 (4)
Maximum obstacle climbing ability mm (in) 100 (4)
Maximum safe descendable kerb height mm (in) 100 (4)
Force to operate Accelerator control Newtons (lbs) 2 (0.45)
Force to operate Freewheel lever Newtons (lbs) 45 (10.1)
Force to operate Emergency brake lever Newtons (lbs) 60 (13.5)
Ambient operating temperature range °C (°F) 2 (35.6) to 40 (104)
USB Accessory outlet Voltage & max. current 5V dc / 3 Amps
This scooter meets the relevant requirements of ISO 7176:14 2008 *Range on full charge and flat ground. Due to a policy of
continual improvement, Electric Mobility Euro Ltd. reserves the right to change specifications without prior notice.
27
