Items Needed
1. Supply power to the VoIP Phone using battery backed up 12vdc source or PoE
(using 2100-VOIPPOE)
2. Connect Ethernet Port of VoIP Phone to network using supplied Ethernet cable
3. Connect analog phone to phone port on VoIP Board
a. Lift handset of analog phone (dial tone should be heard)
b. Dial * , * , * , to enter menu
c. Dial 0 , 2 , to have VoIP Phone playback current IP address (please write down for reference)
d. Dial # , 0 , 3 , to have VoIP Phone playback current subnet mask (please write down for
reference)
e. Hang up analog phone
4. Change IP address of computer to match IP address scheme of VoIP Phone
5. Turn off wireless card on computer (if applicable)
6. Log into VoIP Phone
a. Enter VoIP Phone IP address into web browser (Google Chrome or Mozilla Firefox is preferred)
b. Log into Phone
LOGIN: Admin PASSWORD: Admin
Page 2
• Rath 2100-VoIP Phone
• Static IP address for VoIP Phone
• IP address of SIP Server
Note: Address for VoIP Phone must be on the same network as SIP Server
• Name, Authentication Password, and Authentication ID for SIP Extension
• PC with Network Interface Card attached to same network as SIP Server
• Battery backed up 12vdc power source
• Standard Analog Telephone
Setting Up VoIP Phone for Static IP Address
POE Power Port (if using POE)
To Next Page
