SENSE BOARD (Sensor Board)
The iX3M Reb can use the Sensor Board (sold separately) to monitor up to 3 oxygen
sensors.
The RATIO® Sensor Board dedicated manual (how to plug, how to calibrate, how to use, etc.) is
available on:
http://www.ratio-computers.com/support/
(manuals section)
For iX3M Reb only
O2 SENSOR
SENSORBOARD:
O2 S1: 0.00
O2 S2: 0.00
O2 S3: 0.00
CO2 S1: 0
F02 CALIB:
SAVE 02
b
A C D
ExIT
NExT
VAlUE
ON
/OFF
ON
/OFF
OFF
-.-- OFF
-.-- OFF
-.-- OFF
-.-- OFF
100
SAVE CO2
