EMISSION RELATED PARTS INCLUDE THE FOLLOWING:
1) Fuel Metering System:
a) Gasoline carburetor assembly and its internal components.
b) Fuel fi lter (if so equipped)
c) Carburetor gaskets
d) Fuel pump (if so equipped)
2) Air Induction System including:
a) Intake pipe/manifold
b) Air cleaner
3) Ignition System including:
a) Spark plug
b) Ignition module/coil
4) Catalytic Muffl er Assembly (if so equipped) including:
a) Muffl er gasket
b) Exhaust manifold
5) Miscellaneous including:
a) Hoses, belts and connectors.
3
Safe ty Rules .............................................2
Prod uct Spec i fi ca tions ..............................4
Pre-Op er a tion...........................................4
Op er a tion..................................................5
Maintenance Sched ule............................. 6
Maintenance..........................................6-7
Ser vice and Ad just ments..........................7
Trou ble shoot ing .....................................8-9
Torque Values ..........................................9
Re pair Parts.......................................10-11
TABLE OF CONTENTS
IMPORTANT: This engine is shipped WITHOUT OIL OR GASOLINE.
KNOW YOUR ENGINE
READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OP ER AT ING
YOUR ENGINE. Compare the illustrations with your engine to familiarize yourself with
the location of various controls and adjustments. Save this manual for future reference.
Fuel tank
Warning label
Carburetor
Muffl er
Spark plug
Oil cap with dipstick
Air
fi lter
Gasoline fi ller cap
Primer (optional)
Start/Stop
switch
(optional)
Recoil
starter
handle
E.P.A. label
Fuel fi lter
To Next Page
