1-5.Before installation
In order to pull CF Cards easily out of a CF Card Slot, a pull-out sticker comes
with the CF60U package. If an equivalent sticker doesn’t come with your
PDA, or your PDA doesn’t have an eject button, stick this pull-out sticker as
shown below in order to pull CF Cards easily.
Direction of insert
Stick the pull-out sticker on the back
Serial # sticker
•Using cross cables:
You need to use the cross cable based on the figure as shown below if you use
cross cables:
Signal Signal
DTR DTR
DSR DSR
DCD DCD
RTS RTS
CTS CTS
TXD TXD
RXD RXD
GND GND
