60
12 IMPIANTO IDRAULICO
12 HYDRAULIC SYSTEM
12 HYDRAULIKANLAGE
12 INSTALLATION HYDRAULIQUE
12 INSTALACIÓN HIDRÁULICA
M
F
M
F
M
G
A
C
E
L
D
B
P
P1
T
e
d
PT
A
B
D
M
C
E
G
P
T
BOSCH REXROTH OIL CONTROL BUCHER HYDRAULIC
A serbatoio tank
B ltro aspirazione intake lter
C Motore elettrico electric motor
D Pompa pump
E Valvola di max. (p=180 bar ) safety valve (p=180 bar)
F Valvola controllo velocità discesa down speed valve
G Valvola discesa down valve
L valvola di ritegno check valve
M Cilindro cylinder
T Sato cilindro cylinder relief
12
0484-M004-4
