ADESIVI E DISPOSITIVI SEGNALAZIONE DI PERICOLO
HAZARD WARNING STICKERS AND DEVICES
RIF.
REF
CODICE
CODE
DESCRIZIONE
DESCRIPTION
APPLICAZIONE
APPLICATION
1
99990114 Targhetta indice rotazione Rotation index plate
RAV635-640-660.
3-.3.46__.4-.4.46__.5.55__.6.55 (SI-ISI)
2
904265 Nastro zebrato 500 mm Striped tape 500 mm
3
999908660 Tabella livello olio Oil level table
999912530 Targhetta 220V 60Hz 1Ph 220V 60Hz 1Ph plate
999912430 Targhetta 230V 50Hz 1Ph 230V 50Hz 1Ph plate
999912520 Targhetta 380V 60Hz 3Ph 380V 60Hz 3Ph plate
999912510 Targhetta 220V 60Hz 3Ph 220V 60Hz 3Ph plate
999912390 Targhetta 230V 50Hz 3Ph 230V 50Hz 3Ph plate
4
999912380 Targhetta 400V 50Hz 3Ph 400V 50Hz 3Ph plate
5
99990758
Targhetta autoadesiva
pericolo
Self-sticking danger plate
6
999911760 Etichetta allarme acustico Acoustic alarm label
TUTTI I MODELLI – ALL MODELS
99990637 Targhetta portata kg 3500 Capacity kg 3500 plate
TUTTI I MODELLI – ALL MODELS
RAV635 (SI / ISI)
999909520 Targhetta portata kg 4200 Capacity kg 4200 plate
TUTTI I MODELLI – ALL MODELS
RAV640 (SI / ISI)
99990495 Targhetta portata kg 5000 Capacity kg 5000 plate
TUTTI I MODELLI – ALL MODELS
RAV650 (SI / ISI)
7
99990809 Targhetta portata kg 6000 Capacity kg 6000 plate
TUTTI I MODELLI – ALL MODELS
RAV660 (SI / ISI)
8
Targhetta matricola Number plate TUTTI I MODELLI – ALL MODELS
99990637 Targhetta portata kg 3500 Capacity kg 3500 plate
RAV 635.1-.2-.3-.4 (SI-ISI)
RAV 640.1-.2-.3-.4-.3.46-.4.46 (SI-ISI)
RAV 650.3-.4 (SI-ISI)
RAV 660.3-.4 (SI-ISI)
9
999908950 Targhetta portata kg 4000 Capacity kg 4000 plate
RAV 640.5.55-.6.55 (SI-ISI)
RAV 650.1.55-.2.55-.5.55-.6.55 (SI-ISI)
RAV 660.1.55-.2.55-.5.55-.6.55 (SI-ISI)
10
99990657 Targhetta marchio RAV RAV mark plate
11
999909850 Targhetta istruzioni Instructions label
TUTTI I MODELLI – ALL MODELS
