Raven CR7 Update Manual

PAGE 13/17 | Update manual | 016-8000-xxx EN | Rev. A
UPDATE STU (STEERING CONTROLLER, NEARBY HYDRAULIC MANIFOLD) | CR7 WITH SGC STEERING | UPDATE
CONTROLLERS
20
Check in the bottom of the screen if there is
busload (connection).
21
Go to the next tab (MyDevice)
Set for Pre-selection: Diagnostic Service
Tool
22
In this tab (MyDevice), Press Connect (on
the bottom of the screen).
23
Go to the tab Flash.
Press Refresh to see all the modules which
are on the CANbus.
