Raven CR7 Update Manual

UPDATE STU (STEERING CONTROLLER, NEARBY HYDRAULIC MANIFOLD) | CR7 WITH SGC STEERING | UPDATE
CONTROLLERS
PAGE 12/17 | Update manual | 016-8000-xxx EN | Rev. A
Raven Industries Inc.
4 UPDATE STU (STEERING CONTROLLER, NEARBY HYDRAULIC MANIFOLD)
#
Description
16
Connect the USB to CAN module to the
laptop
17
Connect the 4-pin DT connector to the 4-pin
DT connector in the cabling (CR7 terminal
harness, 115-8000-027)
18
Open the CANtool
19
Select for Hardwaremanufacturer: SysWorxx
Select for Hardware Channel: 1
Press Initialize
