UPDATE SGC (RAVEN ISO STEERING CONTROLLER) | CR7 WITH SGC STEERING | UPDATE CONTROLLERS
PAGE 8/17 | Update manual | 016-8000-xxx EN | Rev. A
Raven Industries Inc.
05
After pressing connect, the ‘Bus Traffic’ must
be green. All the modules on the bus are
shown.
06
Press on ‘Browse’.
07
Search for the right update file
SGC = P449-SGC-Standard_v1_1_1_2.hex
(or higher)
08
Once the file is selected, the SGC should
color lightblue (description is different then
in picture, description is SGC).
