Manual # 016-0130-061 Rev A 10/06
1
C HAPTER
I
NTRODUCTION
Congratulations on your purchase of the Raven PowerGlide Autoboom system!
This system is designed to provide worry-free operation of your hydraulically
controlled booms. Once set up, your system is very easy to use and requires
almost no attention. When you first install your system, it will need to be cali-
brated. To calibrate your system, make sure it is warmed up and that the hydraulic
oil is at normal operating temperature. If you fail to warm the system, it may not
perform properly. It is also important to make sure the machine is running at a suf-
ficient engine speed so that the hydraulic pump is able to supply full flow to the
system.
The following instructions are designed to assist you in the proper calibration of
your PowerGlide system. Installation should be complete before calibrating the
system. If you have any questions regarding the installation of the system, see the
Autoboom Installation Manual for the specific machine you are using.
Important: For open center hydraulic models, all calibration
procedures should be done at full engine RPM.
