Machine Settings: 43
CHAPTER 6 MACHINE SETTINGS
The following offers recommended initial settings for OEM manufacturer.
NOTE: These settings are only intended to assist with initial set up of the machine and test weight
calibrations should be performed to validate and tune these settings.]
TABLE 1.
OEM Machine Settings
Artex Arts Way Kuhn
SB SBX CB
Truck
Mounted
X700 X900 PXL1100
Fan/Spinner RPM 1 1 1
RPM 1 Cal 1 1 1
RPM Low Limit 400 800 800
RPM High Limit 2000 1200 1500
Coil Frequency (Hz) 100 100 100
PWM High Limit (%) 100 100 100
PWM Low Limit (%) 20 20 20
PWM Start Up % 25 25 25
Pulses/Revolution 200 942 2180
Spreader Constant 6 5.1 4.4
Box
Dependent
29.6 26.3 34.8
Gate Height (Max.) 48 in. [121.9 cm]
51 in.
[129.5 cm]
53 in.
[134.6 cm]
70 in.
[177.8 cm]
TABLE 2.
Scale Settings
Artex
Arts
Way
Kuhn
4 Pt 5 Pt 6 Pt 8 Pt 5 Pt -
Cal Value 36904 46130 55356 73808 80000
Contact
