Raven RCM User Manual

016-0171-694 Rev. B 7
INTRODUCTION
MACHINE TYPES
The information provided in this manual is intended for the following machine types:
NOTE: See Chapter 3 for Setup, Calibration, and Operation Instructions. Settings depicted are generic values.
Reference Chapter 6, Machine Settings, for machine specific settings.
RCM LVL 0 – SCALE ONLY
NOTE: RCM Level 0 does not offer dynamic calibration, cleanout mode, or gate height monitoring features.
RCM LVL 0 (Scale Only) does not provide product or task control features with base functionality. These features
may be unlocked to achieve dry manure and litter application control features if desired.
RCM LVL 3 – DRY MANURE/LITTER APPLICATION CONTROL
RCM Level 3 is required for dynamic calibration, cleanout mode, and gate height monitoring features and is only
available for granular spreaders operating in the dry manure/litter application mode and equipped with a product
scale.
When paired with a scale system, the Raven Rate Control Module (RCM) is capable of compensating for varying
product density within a spreader load. This capability offers optimal consistency of application even when the
product composition is highly variable.
TABLE 1.
RCM Machine Types
Machine
Type
Feature
Unlock
Level
Application
Type
Application Mode Uses
Scale Only 0 N/A
General purpose scale without product
control.
Pull-Behind
Spreader
3
Dry Manure/
Litter
Granular full width control using litter or
manure application control features.
Self-
propelled
Spreader
3
Dry Manure/
Litter
Granular full width control using litter or
manure application control features.
TABLE 2.
Applicable Part Numbers for Scale Only Applications
Part Number Description
063-0173-940
Raven Rate Control Module - Level 0
117-7100-004 Kit - RCM LVL 0 Gen 1 ISOBUS ECU Harness
117-7100-001
Kit - RCM LVL 0 Gen 3 ECU Harness
TABLE 3.
Applicable Part Numbers for Dry Manure/Litter Applications
Part Number Description
063-0173-953 Raven Rate Control Module - Level 3
117-7100-007 Kit - RCM LVL 3 Gen 1 ISOBUS ECU Harness
117-7100-008 Kit - RCM LVL 3 Gen 3 ECU Harness
