Chapter 1
2 Viper® 4 and Viper 4+ Installation Manual
Read this manual and the operation and safety instructions included with the equipment and/or controller
carefully before installing the Raven Viper 4 or 4+.
• Follow all safety information presented within this manual.
• If you require assistance with any portion of the installation or service of Raven equipment, contact a local
Raven dealer for support.
• Follow all safety labels affixed to the system components. Be sure to keep safety labels in good condition
and replace any missing or damaged labels. To obtain replacements for missing or damaged safety labels,
contact a local Raven dealer.
When operating the machine after installing the Viper 4 or 4+, observe the following safety measures:
• Be alert and aware of surroundings.
• Do not operate the Viper 4 or 4+ while under the influence of alcohol or an illegal substance.
• Remain in the operator’s position in the machine at all times when the Viper 4 or 4+ is engaged in product
control functions or while any additional automated features are operating. Disable these functions or
features when exiting the operator’s position.
• Maintain a safe working distance from other individuals. The operator is responsible for disabling the Viper
4 or 4+ or any system features when the safe working distance has been diminished.
Instructions for Wire Routing
The word harness is used to mean all electrical leads and cables, bundled and unbundled. When installing
harness, secure it at least every 30 cm (12in) to the frame. Follow existing harness as much as possible and
use these guidelines:
Harness should not contact or be attached to:
• Lines and hoses with high vibration forces or pressure spikes
• Lines and hoses carrying hot fluids beyond harness component specifications
Avoid contact with any sharp edge or abrading surfaces such as, but not limited to:
• Sheared or flame cut edges
• Edges of machined surfaces
• Fastener threads or cap screw heads
• Ends of adjustable hose clamps
• Wire exiting conduit without protection, either ends or side of conduit
• Hose and tube fittings
NOTICE
