Frame Wiring Harness Schematic 39569 Rev D

40 1 5V PWR 18 RED/YLW SP4 -

40 4 5V GRD 18 BLK/YLW SP5 -

41 2 FRAME GRD 14 BLK SP11 -

42 2 PUMP GRD 14 BLK SP13 -

43 4 KEY PWR 18 RED SP6 -

43 5 FRAME GRD 18 BLK SP11 -

44 A 5V PWR 18 RED/YLW SP4 -

44 B 5V GRD 18 BLK/YLW SP5 -

44 C - - - - -

45 B VALVE GRD 14 BLK SP1 -

46 2 VALVE GRD 14 BLK SP1 -

47 1 5V GRD 18 BLK/YLW SP5 -

47 2 5V PWR 18 RED/YLW SP4 -

48 1 5V GRD 18 BLK/YLW SP5 -

48 2 5V PWR 18 RED/YLW SP4 -

49 1 5V GRD 18 BLK/YLW SP5 -

49 2 5V PWR 18 RED/YLW SP4 -

50 1 5V GRD 18 BLK/YLW SP5 -

50 2 5V PWR 18 RED/YLW SP4 -

51 1 5V GRD 18 BLK/YLW SP5 -

51 2 5V PWR 18 RED/YLW SP4 -

52 - FRAME GRD 14 BLK SP11 -

53 - PUMP GRD 14 BLK SP13 -

59 1 TILT SOL 16 ORG SP14 -

54 - LOCKPIN GRD 16 BLK 75 -

55 4 KEY PWR 18 RED SP6 -

55 5 FRAME GRD 18 BLK SP11 -

56 2 PUMP GRD 14 BLK SP13 -

58 A KEY PWR 18 RED SP6 -

58 C FRAME GRD 18 BLK SP11 -

59 2 PINS CLSD 18 GRN SP12 -

61 - BATT + 8 RED SP10 -

62 1 KEY PWR 18 RED SP6 -

62 4 LGT GRD 18 BLK SP8 -

63 1 LGT PWR 14 YLW SP7 -
