Rayco C120R - Jumper Harness Schematic 39570

To Next Page

To Previous Page

C120R Operator Service Maintenance Manual

800.392.2686

FROM WIRE DESCRIPTION

GAUGE COLOR

PLUG# PIN# (FUNCTION IMPRINT) PLUG# PIN #

39570-16

01 1 LGT PWR 18 BLK 02 1

01 2 LGT GRD 18 WHT 02 2

39570-17

01 A CAN + NOTE #1 YLW 02 A

01 B CAN - NOTE #1 GRN 02 B

01 C CAN SHIELD NOTE #1 --- 02 C

39570-18

01 A CAN + NOTE #1 YLW 02 A

01 B CAN - NOTE #1 GRN 02 B

01 C CAN SHIELD NOTE #1 --- 02 C

39570-19

01 - 30A 10 RED 02 -

01 - 50A 10 RED 03 -

39570-20

01 1 SUPPLY 18 BLU 02 1

01 3 SIGNAL 18 ORG 02 3

39570-21

01 1 WIPER PWR 14 RED/WHT 02 -

01 2 WASH 14 WHT 03 -

39570-22

01 A FRAME GRD 16 BLK 02 -

01 B KEY PWR 16 ORG 03 -

01 C SIG 16 RED 04 -

Jumper Harness Schematic 39570
