5.YoucanalsoSwapDirectionoftherulersothat

thebearingbecomesthebearingfromendpoint

tostartpoint.

6.Ifyouwanttherulerdisplayedafteryouhave

closedthemeasuremenu,selectRulersothat

Onishighlighted.

SelectingdisplayrulerwillswitchtherulerOn

andOff.

7.SelectBackorOktoexitthemeasuremenu

leavingthecurrentmeasurementon-screen.

Repositioningtheruler

Youcanrepositionarulerbyfollowingthesteps

below.

1.Selectthecurrentruler.

Therulercontextmenuisdisplayed.

2.SelectMeasure.

Youcannowrepositiontherulerasrequired.
